9.2.3. Basic Atlas plotting

Plot the regions of a reference atlas (Harvard-Oxford and Juelich atlases).

9.2.3.1. Retrieving the atlas data

from nilearn import datasets

dataset_ho = datasets.fetch_atlas_harvard_oxford('cort-maxprob-thr25-2mm')
dataset_ju = datasets.fetch_atlas_juelich('maxprob-thr0-1mm')

atlas_ho_filename = dataset_ho.filename
atlas_ju_filename = dataset_ju.filename

print('Atlas ROIs are located at: %s' % atlas_ho_filename)
print('Atlas ROIs are located at: %s' % atlas_ju_filename)

Out:

Atlas ROIs are located at: <class 'nibabel.nifti1.Nifti1Image'>
data shape (91, 109, 91)
affine:
[[   2.    0.    0.  -90.]
 [   0.    2.    0. -126.]
 [   0.    0.    2.  -72.]
 [   0.    0.    0.    1.]]
metadata:
<class 'nibabel.nifti1.Nifti1Header'> object, endian='<'
sizeof_hdr      : 348
data_type       : b''
db_name         : b''
extents         : 0
session_error   : 0
regular         : b''
dim_info        : 0
dim             : [  3  91 109  91   1   1   1   1]
intent_p1       : 0.0
intent_p2       : 0.0
intent_p3       : 0.0
intent_code     : none
datatype        : uint8
bitpix          : 8
slice_start     : 0
pixdim          : [1. 2. 2. 2. 1. 1. 1. 1.]
vox_offset      : 0.0
scl_slope       : nan
scl_inter       : nan
slice_end       : 0
slice_code      : unknown
xyzt_units      : 0
cal_max         : 0.0
cal_min         : 0.0
slice_duration  : 0.0
toffset         : 0.0
glmax           : 0
glmin           : 0
descrip         : b''
aux_file        : b''
qform_code      : unknown
sform_code      : aligned
quatern_b       : 0.0
quatern_c       : 0.0
quatern_d       : 0.0
qoffset_x       : -90.0
qoffset_y       : -126.0
qoffset_z       : -72.0
srow_x          : [  2.   0.   0. -90.]
srow_y          : [   0.    2.    0. -126.]
srow_z          : [  0.   0.   2. -72.]
intent_name     : b''
magic           : b'n+1'
Atlas ROIs are located at: <class 'nibabel.nifti1.Nifti1Image'>
data shape (182, 218, 182)
affine:
[[   1.    0.    0.  -91.]
 [   0.    1.    0. -126.]
 [   0.    0.    1.  -72.]
 [   0.    0.    0.    1.]]
metadata:
<class 'nibabel.nifti1.Nifti1Header'> object, endian='<'
sizeof_hdr      : 348
data_type       : b''
db_name         : b''
extents         : 0
session_error   : 0
regular         : b''
dim_info        : 0
dim             : [  3 182 218 182   1   1   1   1]
intent_p1       : 0.0
intent_p2       : 0.0
intent_p3       : 0.0
intent_code     : none
datatype        : uint8
bitpix          : 8
slice_start     : 0
pixdim          : [1. 1. 1. 1. 1. 1. 1. 1.]
vox_offset      : 0.0
scl_slope       : nan
scl_inter       : nan
slice_end       : 0
slice_code      : unknown
xyzt_units      : 0
cal_max         : 0.0
cal_min         : 0.0
slice_duration  : 0.0
toffset         : 0.0
glmax           : 0
glmin           : 0
descrip         : b''
aux_file        : b''
qform_code      : unknown
sform_code      : aligned
quatern_b       : 0.0
quatern_c       : 0.0
quatern_d       : 0.0
qoffset_x       : -91.0
qoffset_y       : -126.0
qoffset_z       : -72.0
srow_x          : [  1.   0.   0. -91.]
srow_y          : [   0.    1.    0. -126.]
srow_z          : [  0.   0.   1. -72.]
intent_name     : b''
magic           : b'n+1'

9.2.3.2. Visualizing the Harvard-Oxford atlas

from nilearn import plotting

plotting.plot_roi(atlas_ho_filename, title="Harvard Oxford atlas")
plot atlas

Out:

<nilearn.plotting.displays.OrthoSlicer object at 0x7fc02c265d00>

9.2.3.3. Visualizing the Juelich atlas

plotting.plot_roi(atlas_ju_filename, title="Juelich atlas")
plot atlas

Out:

<nilearn.plotting.displays.OrthoSlicer object at 0x7fc02a01cf40>

9.2.3.4. Visualizing the Harvard-Oxford atlas with contours

plotting.plot_roi(atlas_ho_filename, view_type='contours',
                  title="Harvard Oxford atlas in contours")
plotting.show()
plot atlas

Out:

/home/nicolas/GitRepos/nilearn-fork/nilearn/plotting/displays.py:101: UserWarning: No contour levels were found within the data range.
  im = getattr(ax, type)(data_2d.copy(),

9.2.3.5. Visualizing the Juelich atlas with contours

plotting.plot_roi(atlas_ju_filename, view_type='contours',
                  title="Juelich atlas in contours")
plotting.show()
plot atlas

Out:

/home/nicolas/GitRepos/nilearn-fork/nilearn/plotting/displays.py:101: UserWarning: No contour levels were found within the data range.
  im = getattr(ax, type)(data_2d.copy(),

Total running time of the script: ( 0 minutes 47.637 seconds)
